Lenovo ThinkServer TS430 Hardware Maintenance Manual

InstallingtheIntelligentDiagnosticsModule
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstandingthe“Safetyinformation”
onpageiiiand“Guidelines”onpage85.
ThistopicprovidesinstructionsonhowtoinstalltheIntelligentDiagnosticsModule.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Note:Dependingonthemodel,yourservermightlookslightlydifferentfromtheillustrationsinthistopic.
ToinstalltheIntelligentDiagnosticsModule,dothefollowing:
1.Removeallmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,disconnectall
powercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtotheserver.
2.Removetheservercover.See“Removingtheservercover”onpage87.
3.Removethefrontbezel.See“Removingandreinstallingthefrontbezel”onpage89.
4.Touchthestatic-protectivepackagethatcontainstheIntelligentDiagnosticsModuletoanyunpainted
surfaceontheoutsideoftheserver.Then,taketheIntelligentDiagnosticsModuleoutofthepackage.
5.ConnectthesignalcabletotherearoftheIntelligentDiagnosticsModule.
6.RoutethesignalcableoftheIntelligentDiagnosticsModulethroughthecorrespondingholeinthe
chassisandpositiontheIntelligentDiagnosticsModuleonthechassissothatthescrewholeinthe
IntelligentDiagnosticsModuleisalignedwiththecorrespondingscrewhole
1inthechassis.Then,
installthescrewtosecuretheIntelligentDiagnosticsModuleinplace.
Figure59.InstallingtheIntelligentDiagnosticsModule
7.Removethefrontsystemfan(s).See“Replacingthefrontsystemfan”onpage158.
Chapter6.Installing,removing,orreplacinghardware121
