Lenovo ThinkServer TS430 Hardware Maintenance Manual

Thefollowingillustrationshowsthecomponentsofservermodelswithvetoeight3.5-inchhot-swap
harddiskdrives.
Figure11.Componentsofservermodelswithvetoeight3.5-inchhot-swapharddiskdrives
1IntelligentDiagnosticsModule(availableinsome
models)
13Frontsystemfan1
2Frontpanel
14Frontsystemfan2
3Opticaldrivebay2(withanopticaldriveinstalled
insomemodels)
15Systemboardbattery
4Opticaldrivebay1(withanopticaldriveinstalled)16Low-prolePCIcardbracket
5Hard-disk-drivebay7
17MainPCIcardbracket
6Hard-disk-drivebay618Expansioncard
7Hard-disk-drivebay5
19Heatsinkandfanassembly
8Hard-disk-drivebay4
20Systemboard
9Hard-disk-drivebay3
21Rearsystemfan
10Hard-disk-drivebay222Powersupply
11Hard-disk-drivebay1
23Fourmemoryslots(installedmemorymodulesvaryby
model)
12Hard-disk-drivebay0
•Formoreinformationabout1to4,see“Frontviewoftheserver”onpage15.
26ThinkServerTS430HardwareMaintenanceManual
