Lenovo ThinkServer TS430 Hardware Maintenance Manual

Thefollowingillustrationshowsthecomponentsofservermodelswithuptoeight2.5-inchhot-swapSAS
harddiskdrives.
Figure12.Componentsofservermodelswithuptoeight2.5-inchhot-swapSASharddiskdrives
1IntelligentDiagnosticsModule(availableinsome
models)
12Hard-disk-drivebay0
2Frontpanel
13Frontsystemfan1
3Opticaldrivebay2(withanopticaldriveinstalled
insomemodels)
14Systemboardbattery
4Opticaldrivebay1(withanopticaldriveinstalled)15Low-prolePCIcardbracket
5Hard-disk-drivebay7
16MainPCIcardbracket
6Hard-disk-drivebay617Expansioncard
7Hard-disk-drivebay5
18Heatsinkandfanassembly
8Hard-disk-drivebay4
19Systemboard
9Hard-disk-drivebay3
20Rearsystemfan
10Hard-disk-drivebay221Powersupply
11Hard-disk-drivebay1
22Fourmemoryslots(installedmemorymodulesvaryby
model)
•Formoreinformationabout1to4,see“Frontviewoftheserver”onpage15.
Note:TheIntelligentDiagnosticsModule1isonlyavailableinsomemodelsandtheIDMpanelalso
variesbymodel.See“IntelligentDiagnosticsModule”onpage18.
28ThinkServerTS430HardwareMaintenanceManual
