Lenovo ThinkServer TS430 Hardware Maintenance Manual

Thefollowingillustrationshowsthecomponentsofservermodelswithuptofour3.5-inchhot-swaphard
diskdrives.
Figure13.Componentsofservermodelswithuptofour3.5-inchhot-swapharddiskdrives
1IntelligentDiagnosticsModule(availableinsome
models)
9Frontsystemfan1
2Frontpanel
10Systemboardbattery
3Opticaldrivebay2(withanopticaldriveinstalled
insomemodels)
11Expansioncard(variesbymodel)
4Opticaldrivebay1(withanopticaldriveinstalled)
12Heatsinkandfanassembly
5Hard-disk-drivebay3
13Systemboard
6Hard-disk-drivebay2
14Rearsystemfan
7Hard-disk-drivebay115Powersupply
8Hard-disk-drivebay0
16Fourmemoryslots(installedmemorymodulesvaryby
model)
•Formoreinformationabout1to4,see“Frontviewoftheserver”onpage15.
Note:TheIntelligentDiagnosticsModule1isonlyavailableinsomemodelsandtheIDMpanelalso
variesbymodel.See“IntelligentDiagnosticsModule”onpage18.
•Thereisa3.5-inchhot-swapharddiskdriveoradummyhard-disk-drivetrayinstalledineach
hard-disk-drivebay(
5to8).
Note:Thenumberoftheinstalledharddiskdrivesvariesbymodel.Forthevacantdrivebay,thereisa
dummyhard-disk-drivetraytocovertheplace.
30ThinkServerTS430HardwareMaintenanceManual
