SomeservermodelscomewitharequiredRAIDcardtoprovideadvancedSATA/SAShardwareRAID

functionstotheserver.YoualsocanpurchasetheRAIDcardfromLenovoandinstallitintomodelsthat

supporttheRAIDcardtogetadvancedSATA/SAShardwareRAIDfunctions.See“Installingorremoving

theRAIDcard”onpage103

.

Notes:

•TheoptionkitfortheRAIDcardisdesignedfordifferenttypesofserversandmightcontainadditional

cablesthatarenotrequiredforyourserver.

•ForservermodelswithmorethanfourharddiskdrivesormodelsthatuseSASharddiskdrives,a

RAIDcardmustbeinstalled.

YourserversupportsthefollowingRAIDcards:

•ThinkServerRAID500Adapter

•ThinkServerRAID700Adapter

ThinkServerRAID500Adapter

ThefollowingillustrationshowstheconnectorsontheThinkServerRAID500Adapter.

Figure17.ThinkServerRAID500Adapter

1Port03RAID5keyconnector

2Port14Externalconnector

1Port0

Usedtoconnectamini-SASsignalcable.See“Connectingthecables”onpage39.

2Port1

Usedtoconnectamini-SASsignalcable.See“Connectingthecables”onpage39.

3RAID5keyconnector

UsedtoconnectaThinkServerRAID500UpgradeKeyforAdvancedRAID.See“FortheThinkServerRAID

500Adapter:InstallingorremovingtheThinkServerRAID500UpgradeKeyforAdvancedRAID”onpage105.

4Externalconnector

Usedtoconnecta2-pin200mm(7.87inches)RAIDcardtothesystemboardhard-disk-driveLEDcable.

See“Connectingthecables”onpage39.

34ThinkServerTS430HardwareMaintenanceManual
