Thefollowingillustrationshowsthelocationsofthehot-swaphard-disk-drivebackplanes.Youneedtoopen
theservercoverandremovethefrontsystemfanstoaccessthebackplanes.See“Removingtheserver
cover”onpage87and“Replacingthefrontsystemfan”onpage158.
Notes:
1.Dependingonthemodel,yourservermightlookslightlydifferentfromtheillustrationinthistopic.
2.Thefollowingillustrationisbasedonservermodelsthathavevetoeight3.5-inchhot-swapSATAor
SASharddiskdriveswithtwobackplanes1.
Figure19.Hot-swaphard-disk-drivebackplanelocations
Backplanefor3.5-inchhot-swapharddiskdrives
Thistopicprovidesinformationtohelpyoulocatetheconnectorsona3.5-inchhot-swaphard-disk-drive
backplane.
36ThinkServerTS430HardwareMaintenanceManual
