Toconnectthecables,dothefollowing:

1.Dooneofthefollowing:

•FortheThinkServerRAID500Adapter,useone700mm(27.56inches)mini-SAStomini-SAS

signalcable.Connectthemini-SASconnector1totheport0ontheRAIDcard.Then,connect

themini-SASconnector

2tothemini-SASsignalcableconnector1onthe2.5-inchhot-swap

hard-disk-drivebackplane.

•FortheThinkServerRAID700Adapter,useone700mm(27.56inches)mini-SAStomini-SASsignal

cable.Connectthemini-SASconnector5totheports3-0ontheRAIDcard.Then,connect

themini-SASconnector6tothemini-SASsignalcableconnector1onthe2.5-inchhot-swap

hard-disk-drivebackplane.

2.Ifyouhavemorethanfour2.5-inchharddiskdrivesinstalled,dooneofthefollowing.Otherwise,go

tothenextstep.

•FortheThinkServerRAID500Adapter,usetheother700mm(27.56inches)mini-SAStomini-SAS

signalcable.Connectthemini-SASconnector

5totheport1ontheRAIDcard.Then,connect

themini-SASconnector6tothemini-SASsignalcableconnector2onthe2.5-inchhot-swap

hard-disk-drivebackplane.

•FortheThinkServerRAID700Adapter,usetheother700mm(27.56inches)mini-SAStomini-SAS

signalcable.Connectthemini-SASconnector1totheports7-4ontheRAIDcard.Then,connect

themini-SASconnector

2tothemini-SASsignalcableconnector2onthe2.5-inchhot-swap

hard-disk-drivebackplane.

3.Usethe2-pin200mm(7.87inches)RAIDcardtosystemboardhard-disk-driveLEDcable.Connect

oneend4totheexternalconnectorontheRAIDcardandtheotherend3tothehard-disk-drive

LEDconnectoronthesystemboard.

Note:ThelocationoftheexternalconnectorontheRAIDcarddiffersdependingonthetypeofRAID

card.ForinformationabouttheRAIDcardconnectors,see“RAIDcard”onpage33

.

Figure25.Connectingcablesformodelswithuptoeight2.5-inchSAShot-swapharddiskdrivesandonebackplane

ForconnectorlocationinformationabouttheRAIDcard,hot-swaphard-disk-drivebackplane,andthe

systemboard,refertotherelatedtopicsin“Locations”onpage13

.

Forinformationaboutconnectingtheappropriatepowerconnectorofthepowersupplytothebackplane,

see“Hot-swaphard-disk-drivebackplane”onpage35.

Connectingcablesformodelswithuptofour3.5-inchhot-swapharddiskdrivesandonebackplane

Forservermodelswithuptofour3.5-inchSATAhot-swapharddiskdrivesandonebackplane,youcan

connectthecablesinoneofthefollowingways:

42ThinkServerTS430HardwareMaintenanceManual
