4.IfyouaregoingtoremovetheSuperCapacitorModulebracket,gentlypressthetabonthebracketand
pullthebrackettoremoveitfromthechassis.
1
2
Figure70.RemovingtheSuperCapacitorModulebracketfromthechassis
5.IfyouareinstructedtoreturntheoldSuperCapacitorModule,followallpackaginginstructionsand
useanypackagingmaterialsthataresuppliedtoyouforshipping.
InstallingtheThinkServerRAIDSuperCapacitorModule
ToinstalltheThinkServerRAIDSuperCapacitorModule(hereinafterreferredtoastheSuperCapacitor
Module),dothefollowing:
1.Prepareyourserverandremovetheservercover.See“Preparingyourserverinadvanceandremoving
theservercover”onpage57.
2.IfyouhaveremovedtheSuperCapacitorModulebracket,reinstallit.PositiontheSuperCapacitor
Modulebracketonthechassissothatthetabsonthebracketpassthroughthecorrespondingholesin
thechassis.Then,movetheSuperCapacitorModulebracketasshownuntilitissecuredonthechassis.
1
2
Figure71.InstallingtheSuperCapacitorModulebracketintothechassis
Chapter5.Replacinghardware99
