4.RemovetheCPUfromtheCPUsocket.
1
Releasethesmallhandleasshown.
2
LiftthehandleupwarduntilthehandleandtheCPUretainerareinthefullyopenposition.
3
HoldtheCPUbyitssidesandcarefullyliftitstraightupandoutoftheCPUsocket.
Notes:
•DonottouchthegoldcontactsonthebottomoftheCPU.
•DonotdropanythingontotheCPUsocketwhileitisexposed.Thesocketpinsmustbekeptas
cleanaspossible.
3
1
2
Figure77.RemovingtheCPU
5.InstallanewCPU.See“InstallingtheCPU”onpage105.
6.IfyouareinstructedtoreturntheoldCPU,followallpackaginginstructionsanduseanypackaging
materialsthataresuppliedtoyouforshipping.
InstallingtheCPU
ToinstalltheCPU,dothefollowing:
1.Prepareyourserverandremovetheservercover.See“Preparingyourserverinadvanceandremoving
theservercover”onpage57.
2.Laytheserveronitssideforeasieroperation.
3.Removetheheatsinkandfanassembly.See“Removingtheheatsinkandfanassembly”onpage95.
4.Ifneeded,removetheCPU.See“RemovingtheCPU”onpage104.
Chapter5.Replacinghardware105
