Figure89.Connectingthecablesfortheopticaldrives
1Powerconnectorontherearofthesecondaryopticaldrive
2SATAconnectorontherearofthesecondaryopticaldrive
3Powerconnectorontherearoftheprimaryopticaldrive
4SATAconnectorontherearoftheprimaryopticaldrive
5SATAODDconnector2onthesystemboard
6SATAODDconnector1onthesystemboard
Connectingcablesforthetapedrive
Note:Theserverconfigurationwithanon-hot-swappowersupplyisusedasanexample.Yourservermight
comewithtwohot-swapredundantpowersuppliesandapowerdistributionboard.
IfyouareusinganRDXtapedrive,connectthepowerandsignalcablesforthetapedriveasshown.
Chapter5.Replacinghardware115
