Figure90.ConnectingthecablesfortheRDXtapedrive
1PowerconnectorontherearoftheRDXtapedrive
2SignalcableconnectorontherearoftheRDXtapedrive
3USB2.0connectoronthesystemboard
IfyouareusinganLTO-6tapedrive,connectthepowerandsignalcablesforthetapedriveasshown.
1 2
3
Figure91.ConnectingthecablesfortheLTO-6tapedrive
116ThinkServerTS460UserGuideandHardwareMaintenanceManual
