Lenovo ThinkServer TS460 - Page 133

1
3
5 4
Figure94.Cableconnectionforone2.5-inch-drivebackplane
1Powerconnectoronthebackplane
2Mini-SAScableconnector0onthebackplane
3Mini-SAScableconnector1onthebackplane
4Connector1ontheRAIDcard
5Connector0ontheRAIDcard
Ifyourservercomeswithtwo3.5-inch-drivebackplanes,connectthepowerandsignalcablesasshown.
1
2
3
4
6
78
5
Figure95.Cableconnectionfortwo3.5-inch-drivebackplanes
Chapter5.Replacinghardware119
