1Powerconnectoronthepowerdistributionboard3Powerconnectorontheupperbackplane
2Powerconnectoronthepowerdistributionboard5Powerconnectoronthelowerbackplane
4Mini-SAScableconnectorontheupperbackplane7Connector1ontheRAIDcard
6Mini-SAScableconnectorontheupperbackplane8Connector0ontheRAIDcard
Forserverconfigurationswithanexpandercard
Ifyourservercomeswithtwo2.5-inch-drivebackplanes,connectthepowerandsignalcablesasshown.
6
78
1
2
1114 131516 12
3
45
910
Figure96.Cableconnectionfortwo2.5-inch-drivebackplanes
1Powerconnectoronthepowerdistributionboard3Powerconnectorontheupperbackplane
2Powerconnectoronthepowerdistributionboard6Powerconnectoronthelowerbackplane
4Mini-SAScableconnector0ontheupperbackplane12ConnectorEontheexpandercard
5Mini-SAScableconnector1ontheupperbackplane11ConnectorFontheexpandercard
7Mini-SAScableconnector0onthelowerbackplane14ConnectorContheexpandercard
8Mini-SAScableconnector1onthelowerbackplane13ConnectorDontheexpandercard
9Connector1ontheRAIDcard15ConnectorBontheexpandercard
10Connector0ontheRAIDcard16ConnectorAontheexpandercard
Ifyourservercomeswitha3.5-inch-drivebackplaneanda2.5-inch-drivebackplane,connectthepower
andsignalcablesasshown.
