Powersupply
Theservermightcomewithoneofthefollowingpowersupplyconfigurations:
•Onescrew-secured,non-hot-swap300-wattpowersupplyassembly
•Oneortwohot-swap450-wattredundantpowersupplies
Note:Ifyouareusinguninterruptiblepowersupplies(UPS),ensurethatyou
useonlypure-sineUPSwithyourThinkServerserver.
Systemfans
Yourservercomeswiththefollowingfanstoprovidepropersystemcooling
andairflow:
•Oneheatsinkandfanassembly
•Twofrontsystemfans
•Onerearsystemfan
InternaldrivesInternaldrivesaredevicesthatyourserverusestoreadandstoredata.The
internaldrivessupportedbyyourservervarybymodel.
•Internalstoragedrive
–Uptofour3.5-inchhot-swapSerialAdvancedTechnologyAttachment
(SATA)orSerialAttachedSCSI(SAS)harddiskdrives(HDDs)(SCSIis
theacronymforSmallComputerSystemInterface)
–Fivetoeight3.5-inchhot-swapSATAorSASHDDs
–Uptofour3.5-inchnon-hot-swapSATAHDDs
–Uptoeight2.5-inchhot-swapSATAorSASHDDs
–Uptosixteen2.5-inchhot-swapSATAorSASHDDs
–Uptofour3.5-inchandeight2.5-inchhot-swapSATAorSASHDDs
•Opticaldrive
–Uptotwoopticaldrives
–Theserverhastwoopticaldrivebays.Theloweropticaldrivebayis
installedwithaSATAopticaldrive.
•Tapedrive(availableonsomemodels)
YourserversupportsRDXandLTOtapedrivesthatenableyoutostore
dataontapedrivemedia.Toinstallorremoveatapedrive,see“Installing
atapedrive”onpage72
.
Notes:
–Iftheserverhasatapedriveinstalled,ensurethatitisinstalledinthe
lowerbay(theopticaldrivebay1).
–IfyourserverisinstalledwithaWindowsServeroperatingsystem,you
canusetheWindowsBackupprogramtobackupthedatastoredon
tapedrivemedia.Fordetailedinformation,refertotheuserguideofthe
tapedrive.Theuserguideisavailablefordownloadat:
http://www.lenovo.com/UserManuals
Expansionslots
YourserverhasfourPCIeexpansionslotsonthesystemboard.Fordetailed
information,see“Systemboardcomponents”onpage33.
