17Hot-swappowersupplies(2)*
1
18Powerdistributionboard*
2
19Hot-swappowersupplycage*
1
20Powerdistributionboardcage*
1
21Systemboard
3
22CPU
3
23Memorymodules(varybymodel)
1
24Heatsinkandfanassembly
2
Notes:
•*Availableonsomemodels
•
1
Self-serviceCRUs:Partstobeinstalledorreplacedbycustomerthemselves.
•
2
OptionalCRUs:Partscanbeinstalledorreplacedbycustomersortechniciansundercertainterms
oftheapplicablewarrantyservicetypeforyourcountryorregion.
•
3
Non-CRUs:Partsmustbeinstalledorreplacedonlybytrainedservicetechnicians.
BeforeservicingaLenovoproduct,ensurethatyoureadandunderstand“Readthisfirst:safetyinformation”
onpageiii.UseonlypartsprovidedbyLenovoforreplacement.ForacompletelistingofFRUinformation,
suchasFRUpartnumbersandsupportedservermodels,goto:
http://www.lenovo.com/serviceparts-lookup
Hot-swapdriveactivityandstatusLEDs
Eachhot-swapdrivehastwoLEDsonthefront.
12
Figure9.Hot-swapdriveactivityandstatusLEDs
1DriveactivityLED2DrivestatusLEDDescription
OffOff
Thedrivehasfailedorisnotpresent.
GreenOff
Thedriveispresentbutnotinuse.
BlinkinggreenOff
Thedriveisactiveanddataisbeingtransferred.
Green
Blinkingamber
(blinkingrapidly,
aboutfourflashes
persecond)
TheRAIDcontrollerisidentifyingthedrive.
