Lenovo ThinkServer TS460 - Page 39

1DriveactivityLED2DrivestatusLEDDescription
GreenAmber
Oneofthefollowingsituations:
•Thedrivehasfailed.Replacethedrive.
•ThestatusofthedriveisUnconfiguredBad.Replacethedrive.
Note:IfadriveinaRAIDarrayisremovedandthenreinstalled
whiletheserverison,thestatusofthedrivewillbeidentifiedas
UnconfiguredBad.Inthiscase,donotreplacethedrive.You
canchangethedrivestatusintoUnconfiguredGoodusingthe
ThinkServerMegaRAIDSASSoftware.
•ThestatusofthedriveisOffline.Youcanchangethedrive
statusintoOnlineusingtheThinkServerMegaRAIDSAS
Software.
FordetailedinformationaboutusingtheThinkServerMegaRAID
SASSoftware,refertotheThinkServerMegaRAIDSASSoftware
UserGuide.Youcanobtainthemostup-to-datedocumentation
foryourserverfromtheLenovoWebsiteat:
http://www.lenovo.com/UserManuals
Blinkinggreen
Blinkingamber
(blinkingslowly,about
oneflashpersecond)
Thedriveisbeingrebuilt.
Powerdistributionboard
Thepowerdistributionboardisavailableonservermodelswithhot-swappowersupplies.
4 5
1
2
3
Figure10.Rearview
6
7
Figure11.Frontview
Chapter3.Productoverview25
