LenovoThinkServerRAID520iPCIeAdapter
TheRAID520iAdapterprovidesadvancedSATA/SAShardwareRAIDfunctions.Thefollowingillustration
showstheconnectorsontheadapter.
1 2 3
Figure13.LenovoThinkServerRAID520iPCIeAdapter
Connector
Description
1Connector0Usedtoconnecttothemini-SASsignalcableconnectoronthebackplanetosupportHDD0–3.
2Connector1Usedtoconnecttothemini-SASsignalcableconnectoronthebackplanetosupportHDD4–7.
3J3connector
UsedtoconnecttoaThinkServerRAID520iupgradekey.
28ThinkServerTS460UserGuideandHardwareMaintenanceManual
