LenovoThinkServerRAID720iPCIeAdapter
TheRAID720iAdapterprovidesadvancedSATA/SAShardwareRAIDfunctions.Thefollowingillustration
showstheconnectorsontheadapter.
1 2 3
Figure14.ThinkServerRAID720iPCIeAdapter
Connector
Description
1Connector0Usedtoconnecttothemini-SASsignalcableconnectoronthebackplanetosupportHDD0–3.
2Connector1Usedtoconnecttothemini-SASsignalcableconnectoronthebackplanetosupportHDD4–7.
3Thunderbolt
FlashModule
connector
UsedtoconnectaThunderboltMemoryModule.
LenovoThinkServerSAS12GExpanderPCIeCard
ThistopichelpsyoulocatetheconnectorsontheLenovoThinkServerSAS12GExpanderPCIeCard
(hereinafterreferredtoasexpandercard).Theexpandercardisavailableonsomemodels.
Note:TheexpandercardneedstobeinstalledintothePCIeslot3onthesystemboard.
Chapter3.Productoverview29
