1 2 3 4 5 6 7
Figure15.LenovoThinkServerSAS12GExpanderPCIeCard
1ConnectorA2ConnectorB
3ConnectorC4ConnectorD
5ConnectorE6ConnectorF
7ConnectorG
ToconnecttheexpandercardwithRAIDcardsorbackplanes,refertothefollowingtable.
ExpandercardRAID520iAdapterRAID720iAdapter
ConnectorAConnector0Connector0
ConnectorBConnector1Connector1
ConnectorsC–GareusedtoconnecttheMini-SASconnectorsonthebackplanes.
Backplane
Yourserversupportsbackplanesforuptofour3.5-inchdrivesanduptoeight2.5-inchdrives.
Tolocatethebackplanes,see“Servercomponents”onpage22.
Backplaneforuptofour3.5-inchdrives
Thistopicprovidesinformationtohelpyoulocatetheconnectorsonthebackplaneforuptofour3.5-inch
drives.
30ThinkServerTS460UserGuideandHardwareMaintenanceManual
