Figure16.Frontview
Figure17.Rearview
1–4Slot0–slot3
Usedtoconnect3.5-inchdrives.
5Mini-SASsignalcableconnector
Usedtoconnecttothemini-SASconnectorontheRAIDcard.YoualsocanuseaSATAtomini-SASsignal
cabletoconnectthebackplanetotheSATAconnectorsonthesystemboard.
68-pinpowerconnector
Usedtoconnecttoan8-pinpowerconnectoronthepowerdistributionboardorsystemboard.
Backplaneforuptoeight2.5-inchdrives
Thistopicprovidesinformationtohelpyoulocatetheconnectorsonthebackplaneforuptoeight2.5-inch
drives.
Chapter3.Productoverview31
