Figure18.Frontview
Figure19.Rearview
1–8Slot0–slot7
Usedtoconnect2.5-inchdrives.
9Mini-SASsignalcableconnector1
Usedtoconnecttothemini-SASconnectorontheRAIDcard.YoualsocanuseaSATAtomini-SASsignal
cabletoconnectthebackplanetotheSATAconnectorsonthesystemboard.
108-pinpowerconnector
Usedtoconnecttoan8-pinpowerconnectoronthepowerdistributionboardorsystemboard.
11Mini-SASsignalcableconnector0
Usedtoconnectthemini-SASconnectorontheRAIDcard.YoualsocanuseaSATAtomini-SASsignal
cabletoconnectthebackplanetotheSATAconnectorsonthesystemboard.
32ThinkServerTS460UserGuideandHardwareMaintenanceManual
