18-pinpowerconnector
Usedtoconnectthe8-pinpowercableofthepowersupply.
2CPUsocket
UsedtoinstalltheCPU.
3PMBusconnector
UsedtoconnecttothePMBusconnectoronthepowerdistributionboardforthehot-swappowersupplies.
424-pinmainpowerconnector
Usedtoconnectthe24-pinpowercableofthepowersupply.
5MainpowerLED
Indicatestheworkingstatusofthepowersupplytothesystemboard.
MainpowerLEDDescription
Green
Thesystemboardispowerednormally.
Off
Thesystemboardisnotpowerednormally.
6Memoryslots
Usedtoinstallmemorymodules.Fordetailedinformation,see“Memorymoduleinstallationrules”on
page60.
7Frontsystemfan2connector
Usedtoconnectthecableofthefrontsystemfan2.
8Frontsystemfan2LED
Indicatestheworkingstatusofthefrontsystemfan2.
Frontsystemfan2LEDDescription
Blinkingamber
Thefanhasfailed.
Off
Thefanisworkingnormally.
9CPUfanconnector
UsedtoconnecttheCPUfanontheCPUheatsink.
