10CPUfanLED
IndicatestheworkingstatusoftheCPUfan.
CPUfanLED
Description
Blinkingamber
Thefanhasfailed.
Off
Thefanisworkingnormally.
11Frontsystemfan1connector
Usedtoconnectthefrontsystemfan1.
12Frontsystemfan1LED
Indicatestheworkingstatusofthefrontsystemfan1.
Frontsystemfan1LEDDescription
Blinkingamber
Thefanhasfailed.
Off
Thefanisworkingnormally.
13SerialGeneralPurposeInput/Output(SGPIO)connector
UsedtoconnecttheSGPIOconnectorofthemini-SASsignalcablewithfourSATAconnectorsandone
SGPIOconnector.
14151718SATAconnectors
UsedtoconnecttheHDD,opticaldrive,ortapedrive.
Note:IfanM.2SATAdeviceisinsertedinto
21M.2connector,14SATAconnectorforsecondaryODD
isdisabled.
16FrontUSB3.0connector
UsedtoconnectthefrontUSBcable.
1920Frontpanelconnectors
Usedtoconnectthefrontpanelboard.
21M.2connector
UsedtoconnecttheM.2PCIedeviceorM.2SATAdevice.
Note:IfanM.2PCIedeviceisinserted,
27PCIeslot1isdisabled.IfanM.2SATAdeviceisinserted,14
SATAconnectorforsecondaryODDisdisabled.
22USB2.0connectors
UsedtoconnectthesignalcablefortheRDXtapedrive.
Chapter3.Productoverview35
