Attach a USB-compatible device, such as a USB keyboard, USB mouse, or USB storage device.
6 VGA connector
Used to attach a high-performance monitor, a direct-drive monitor, or other devices that use a VGA
connector.
7 1 Gb Ethernet connector 2
8 1 Gb Ethernet connector 1
Used to attach an Ethernet cable for a LAN. Each Ethernet connector has two status LEDs to help you
identify the Ethernet connectivity and activity. For information about the LEDs, see “Rear view LEDs” on page
25.
Ethernet connector 1 can be set as XClarity Controller Network connector. To set Ethernet connector 1 as
XClarity Controller Network connector, start Setup utility, go to BMC Settings ➙ Network Settings ➙
Network Interface Port and select Shared. Then, go to Shared NIC on and select Onboard Port 1.
9 XClarity Controller network connector
Used to attach an Ethernet cable to manage the system using XClarity Controller.
10 Ethernet connector 2 on the LOM adapter
11 Ethernet connector 1 on the LOM adapter
The LOM adapter provides two extra Ethernet connectors for network connections.
Ethernet connector 1 on the LOM adapter can be set as XClarity Controller Network connector. To set the
Ethernet connector 1 as XClarity Controller Network connector, start Setup utility, go to BMC Settings ➙
Network Settings ➙ Network Interface Port and select Shared. Then, go to Shared NIC on and select
PHY Card.
