Lenze · 8400 BaseLine C · Reference manual · DMS 1.6 EN · 01/2014 · TD05 313
11 Function library
11.3 L_PCTRL_1
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Outputs
Parameter
bIOff
BOOL
Switch off I-component of process controller
• Changes can be done online.
• Display parameter: C833/12
TRUE I-component of the process controller is switched off.
nInflu_a
INT
Limitation of the influencing factor in percent
• nInflu_a serves to limit the influencing factor of the PID controller contained in
the FB to a required value (- 199.9 % ... + 199.9 %).
• Scaling: 16384 ≡ 100 %
• Internal limitation to ± 199.9 %
• Display parameter: C830/9
bEnableInfluenceRamp
BOOL
Activate ramp for influencing factor
• Display parameter: C833/13
TRUE Influencing factor of the PID controller is ramped up to the nInflu_a
value.
FALSE Influencing factor of the PID controller is ramped down to "0".
Identifier
Data type
Value/meaning
nOut_a
INT
Output signal
• Internal limitation to ±32767 (±199.9 %)
• Scaling: 16384 ≡ 100 %
bActEqSet
INT
Status output "Setpoint and actual value are identical"
TRUE Setpoint and actual value are identical, i.e. no system deviation avai-
lable.
nPIDOut_a
INT
PID controller output with influencing factor nInflu_a
• There is no connection with the additive input nNSet_a.
• Scaling: 16384 ≡ 100 %
• Display parameter: C245
Parameter Possible settings Info
C222 0.1 500.0 Gain Vp
•Lenze setting: 1.0
C223
20 ms 6000 Reset time Tn
• Lenze setting: 400 ms
C224
0.0 5.0 Differential component Kd
•Lenze setting: 0.0
C225
-199.9 % +199.9 Maximum value of the PID operating
range
• Lenze setting: 199.9 %
C226
-199.9 % +199.9 Minimum value of the PID operating
range
• Lenze setting: -199.9 %
C227
0.0 s 999.9 Acceleration time for the ramp at the
PID output (should be set as steep as
possible)
• Lenze setting: 0.1 s
C228
0.0 s 999.9 Deceleration time for the ramp at the
PID output
• Lenze setting: 0.1 s
Identifier
Data type
Information/possible settings
