Function block library
7-67
SHB9300CRV EN 2.0
Signal Source Note
Name Type DIS DIS format CFG List
CDATA-SEL a 1321/1 dec[abs] 1320/1 1 Profile selection 0 = profile 0 (1. profile)
CDATA-XFACT a 1321/2 dec[%] 1320/2 1 Stretching/compression factor in X direction:
+100% = no compression/stretching
> 100% = compression
< 100% = stretching
CDATA-CYCLE d 1323/1 bin 1322/1 2 Automatic cam profile processing
HIGH = the profiles from C1311 and C1312 are cyclically processed
CDATA-RESET d 1323/2 bin 1322/2 2 = HIGH, if CDATA-CYCLE = LOW, the input CDATA-SEL is immediately
evaluated; if CDATA-CYCLE = HIGH, the profile from C1311 will be
processed
CDATA-REL-SEL d 1323/3 bin 1322/3 2 = HIGH, feed function active
CDATA-XRESET d 1323/4 bin 1322/4 2 = HIGH, sets master value integrator to 0*
CDATA-X-TP d 1323/5 bin 1322/5 2 = HIGH, sets master value integrator to C1317/1
CDATA-HOLD d 1323/6 bin 1322/6 2 = HIGH, avoids cam profile processing
Input has priority over -RESET
CDATA-XIN ph 1325/2 dec[inc] 1324/2 3 Input for the master value position if C1332 = 1
CDATA-XOFFS ph 1325/3 dec[inc] 1324/3 3 Input for offset in X direction (only if C1332 = 0)
CDATA-TP-POS ph 1325/4 dec[inc] 1324/4 3 Touch probe - master value position (if C1332 = 0)
CDATA-DFIN phd 1327/1 dec[rpm] 1326/1 3 Input for digital frequency if (C1332 = 0)
CDATA-ACTCAM a 13301 - - - Output of active cam profile (No.)
CDATA-SEC1* d 13301 - - - HIGH = section 1 active *
CDATA-SEC2* d 13302 - - - HIGH = section 2 active *
CDATA-SEC3* d 13303 - - - HIGH = section 3 active *
CDATA-SEC4* d 13304 - - - HIGH = section 4 active *
CDATA-SEC5* d 13305 - - - HIGH = section 5 active *
CDATA-X0 d 13306 - - - Transition L -> H = zero of the master value integrator
CDATA-X>Xmax d 13307 - - - HIGH = number range exceeded in X direction
CDATA-X<0 d 13308 - - - Display of overrange in X direction
CDATA-BUSY-LENx d 13309 - - - HIGH = outputs CDATA-LENx and CDATA-Y-END are not valid and are
being determined at present (e.g. profile processing)
CDATA-BUSY-LOAD d 13310 - - - HIGH = new cam data are being accepted at present, the controller is
inhibited
(only if input CDATA-LOAD = HIGH)
CDATA-BUSY d 13315 - - - LOW-HIGH signal = The point distribution is not perfect, select less
points.
CDATA-CHK-ERR d 13311 - - - HIGH = the check sum transferred to C0509 does not correspond to the
cam data
CDATA-LEN1* ph 13301 - - - Ouput of the actual X length section 1 of the selected cam profile (65536
inc = 1 encoder rev.)
CDATA-LEN2* ph 13302 - - - Ouput of the actual X length section 2 of the selected cam profile (65536
inc = 1 encoder rev.)
CDATA-LEN3* ph 13303 - - - Ouput of the actual X length section 3 of the selected cam profile (65536
inc = 1 encoder rev.)
CDATA-LEN4* ph 13304 - - - Ouput of the actual X length section 4 of the selected cam profile (65536
inc = 1 encoder rev.)
CDATA-LEN5* ph 13305 - - - Ouput of the actual X length section 5 of the selected cam profile (65536
inc = 1 encoder rev.)
CDATA-ACTLEN ph 13306 - - - Output of the actual master value clock pulse length (65536 inc = 1
encoder rev.)
CDATA-XPOS ph 13307 - - - Output of the master value integrator (65536 inc = 1 encoder rev.)
CDATA-YOUT ph 13308 - - - Set drive position (65536 inc = 1 motor rev.)
CDATA-Y-END ph 13309 - - - Y upper range value act. cam profile (65536 inc = 1 motor rev.)
CDATA-YNOUT phd 13301 - - - Set drive speed
CDATA-N-SYNCH phd 13302 - - - Synchronisation value for synchronised stretching and compression
* the outputs will not be output when using the absolute data model
