Code table
10
Function library
10.20
L
10.20-10
EDS82EV903-1.0-11/2002
Code IMPORTANTPossible settings
No. SelectionLenzeName
C0044* Setpoint 2
(NSET1-N2)
-650.00 {0.02 Hz} 650.00 The value set will be lost when
switching the mains!
• Selectio n, if C0412/2 = FIXED-FREE (not
assigned)
• Displa y if C0412/2 is linked with a signal
source
^ 10.8-15
C0046* Setpoint 1
(NSET1-N1)
-650.00 {0.02 Hz} 650.00 The value set will be lost when
switching the mains!
• Selectio n, if C0412/1 = FIXED-FREE (not
assigned)
• Displa y if C0412/1 is linked with a signal
source
^ 10.8-15
C0047* Torque setpoint or
torque limit value
(
M
C
T
R
L
1
M
S
E
T
)
400 0 {1 %} 400 The value set will be lost when
switching the mains!
^ 10.3-11
q
(MCTRL1-MSET)
Ref.: Rated motor torque detected by motor parameter
identification
Control mode ”Sensorless torque control”
(C0014 = 5):
• Torque setpoint selection if C0412/6 =
FIXED-FREE (not assigned)
• Torque setpoint display if C0412/6 is
linked with a signal source
Control mode ”V/f characteristic control” or
”Vector control ” (C0014 = 2, 3, 4):
• Torque limit value is displayed if
C0412/6 is linked with a signa l source
• C0047 = 400 is displaye d if C0412/6 =
FIXED-FREE (not assigned)
C0049* Additional setpoint
(PCTRL1-NADD)
-650.00 {0.02 Hz} 650.00 The value set will be lost when
switching the mains!
• Selectio n, if C0412/3 = FIXED-FREE (not
assigned)
• Displa y if C0412/3 is linked with a signal
source
C0050*
uSEr
Output frequency
(MCTRL1-NOUT)
-650.00 {Hz} 650.00 Only display: Output frequency without slip
compensation
C0051* Output frequency
with slip
compensation
(MCTRL1-NOUT
+SLIP) or
act. process
controller value
(PCTRL1-ACT)
-650.00 {0.02 Hz} 650.00 The value set will be lost when
switching the mains!
Operation without process controller (C0238
=2):
• Display only: Output frequency with slip
compensation (MCTRL1-NOUT+SLIP)
Operation with process controller (C0238 =
0, 1):
• Selectio n, if C0412/5 = FIXED-FREE (not
assigned)
• Displa y if C0412/5 is linked with a signal
source
^ 10.10-6
C0052* Motor voltage
(MCTRL1-VOLT)
0 {V} 1000 Only display
C0053* DC-bus voltage
(MCTRL1-DCVOLT)
0 {V} 1000 Only display
C0054* Apparent motor
current
(MCTRL1-IMOT)
0.0 {A} 2000.0 Only display
C0056* Controller load
(MCTRL1-MOUT)
-255 {%} 255 Only display
