Lenze E82EV752K4C - Fig. 5.6-3 Standard Mounting with Built-On Mains Filter

Basic units in the power range 45 ... 55 kW
Mounting with fixing brackets and built-on mains filter
5
Basic device installation
5.6
5.6.3
L
5.6-3
EDS82EV903-1.0-11/2002
5.6.3 Mounting with fixing brackets and built-on mains filter
8200vec281
Fig. 5.6-3 Standard mounting with built-on mains filter
 Loosebothscrewsinordertoremovethehousingcover.
 Mounting of the fixing brackets
 Dimensions
0
Mount the drive controllers side by side leaving a certain space for dismounting
the lifting-eye bolt.
Mains filter
Dimensions [mm]
8200 vector
M
a
i
n
s
f
i
l
t
e
r
type A or typ e B
a b1 b4 c c1 d d1 d2 e g k m
E82EV453K4B EZN3x0037H090
3
4
0
9
7
3
5
0
8
2
8
4
2
8
1
0
5
0
3
8
1
0
0
0
2
8
5
1
1
2
8
1
8
E82EV553K4B EZN3x0030H110
340 973 508 284 28 1050 38 1000 285 11 28 18
