Lenze E82EV752K4C - Fig. 5.5-2 Standard Mounting with Footprint Mains Filter 15; Mounting with Fixing Brackets and Footprint Mains Filter

Basic units in the power range 15 ... 30 kW
Mounting with fixing brackets and footprint mains filter
5
Basic device installation
5.5
5.5.2
L
5.5-2
EDS82EV903-1.0-11/2002
5.5.2 Mounting with fixing brackets and footprint mains filter
8200vec293
Fig. 5.5-2 Standard mounting with footprint mains filter 15 ...30 kW
 Loosebothscrewsinordertoremovethehousingcover.Theassemblykitcan
be found under the housing cover.
 Mounting of the fixing brackets
 Dimensions
0
Mount the drive controllers side by side with a certain space to each other in
order to dismount lifting-eye bolts, if necessary.
Dimensions [mm]
8200 vector a b b1 c c1 d d1 d2 e g k m
E82EV153K4B3xx
E82EV223K4B3xx
2
5
0
4
5
6
3
5
0
2
0
5
2
2
4
0
2
2
4
3
7
0
3
4
0
6
5
2
4
1
1
E82EV303K4B3xx
250 456 350 205 22 402 24 370 340 6.5 24 11
