12.5.3 Supplies - 230 V controller
Supply power in the network of 230 V controller, three-phase
Supply terminal 1
402K2C 752K2C 9365 9364 152K2C,
222K2C
551K2C,
751K2C
552K2C 302K2C
P
DC
[kW] 6.5 10.1 57.5 28.8 3.7 1.4 9.0 5.1
P
V
[kW] 0.2 0.3 0.4 0.2 0.1 0.1 0.3 0.2
Supply 2...n
402K2C 5.3
752K2C 7.2 8.3
9365 39.5 45.1 47.0
9364 17.2 19.6 20.4 23.5
152K2C, 222K2C 2.1 2.4 2.5 2.9 3.0
551K2C, 751K2C 0.7 0.8 0.8 1.0 1.0 1.1
552K2C 4.3 4.8 5.1 5.8 6.1 6.9 7.4
302K2C 2.1 2.4 2.5 2.9 3.1 3.5 3.7 4.2
Supply power in the network of 230 V controllers, single-phase
Supply terminal 1
8201, 8202, 551K2C,
751K2C
8204 152K2C, 222K2C 8203
P
DC
[kW] 1.3 3.2 3.3 2.4
P
V
[kW] 0.1 0.1 0.1 0.1
Supply 2...n
8201, 8202, 551K2C,
751K2C
1.1
8204 2.1 2.6
152K2C, 222K2C 2.1 2.6 2.7
8203 1.5 1.9 1.9 2.0
Howtousethetable: 1. Look under ”supply 1” from left to right until you find a controller connected to
the network
2. Look for more devices in the same column for the corresponding power P
DC
and
add the powers until the required sum power is reached. Every added devices
must be supplied.
Empty fields Supply combinations not possible
