Lenze E82EV752K4C - Fig. 5.3-9 Swivelling Lateral Mounting

Basic units in the power range 0.25 ... 2.2 kW
Lateral mounting
5
Basic device installation
5.3
5.3.5
L
5.3-10
EDS82EV903-1.0-11/2002
l
All controllers require a mounting kit:
– Order number E82ZJ001 for 8200 vector 0.25 ... 2.2 kW
8200vec024
Fig. 5.3-9 Swivelling lateral mounting

Bolt here

Rotating point, stops at 45°,90°, 135°, 180°

Bolt here to fasten the controller at 0° position.
Dimensions [mm]
8200 vector Mounting kit a b b
1
b
2
c c
1
d e e
1
E82EV251K2C
E82EV371K2C
186 160 ... 175 120
E82EV551KxC
E82EV751KxC
E82ZJ001 60
246 220 ... 235 180
140 162 6.5 11.5 39
E82EV152KxC
E82EV222KxC
306 280 ... 295 240
Swivelling lateral mounting
