Lenze E82EV752K4C - Fig. 10.8-1 Gain and Offset at Unipolar Setpoint Selection; Fig. 10.8-2 Gain and Offset at Bipolar Setpoint Selection

Configuration of analog and digital setpoints and actual values
Analog setpoints via terminal
10
Function library
10.8
10.8.2
L
10.8-6
EDS82EV903-1.0-11/2002
f
C0011
Offset > 0 %
Deadband
Offset < 0 %
Offset=0%,
gain = 100 %
Gain > 100 %
G
ain
<
100
%
5V
10 V
20 mA
10 kHz
0V
0mA
0kHz
Setpoint
signal
8200vec529
Fig. 10.8-1 Gain and offset at unipolar setpoint selection
f
C0011
-C0011
Offset>0%
Dead-
band
Offset=0%, gain = 100 %
Gain<0%
10 V
-10 V
Setpoint
signal
8200vec530
Fig. 10.8-2 Gain and offset at bipolar setpoint selection
Unipolar setpoint selection
Bipolar setpoint selection
