Codes for parameter setting
Code Possible settings IMPORTANT
No. Name Lenze Selection
C0014
v
Operating mode 2
2 V/f charact eristic control V ~ f
(Linear characteristic with constant V
min
boost)
• Commissioning without motor parameter
identification possible
• Benefit of identification with C0148:
I
m
p
r
o
v
e
d
s
m
o
o
t
h
r
u
n
n
i
n
g
a
t
l
o
w
^ 10.3-1
3 V/f charact eristic control V ~ f
2
(Square-law characteristic with constant V
min
boost)
–
Improved smooth running at low
speed
– V/f ra t e d f re quency (C0015) and slip
(C0021) are calculated and stored.
They do not have to be entered
4 Vector control
For initial selection enter the motor data
5 Sensorless to rque control with speed limitation
• Torque setpoint via C0412/6
• Speed limit ation via setpoint 1 (NSET1-N1), if
C0412/1 is a ssigned, if not via max. frequency
(C0011)
and identify the motor parameters with
C0148
Otherwise commissioning is not
possible
C0015
uSEr
V/f rated frequency 50.00 7.50 {0.02 Hz} 960.00 • C0015 is calculated a nd stored under
C0148 when the motor parameters are
identified
• Settings applies to all possible mains
voltages
^ 10.3-3
^ 10.3-8
C0016
uSEr
V
min
boost à 0.00 {0.01 %} 40.00 à Depending on the controller
Setting applies to all mains voltages
permitted
^ 10.3-3
