9300 Servo PLC
System blocks
2.12 MCTRL_MotorControl
2-62
L
ServoPLC EN 2.0
2.12.17.8 OH4 - Heatsink temperature monitoring (adjustable)
This monitoring function protects the controller.
No. Monitoring function Display System variable TRIP Message Warning Off
054 Heatsink temperature (adjustable) OH4 MCTRL_bKuehlGreaterC0122_b • ü
• Default setting ü Setting possible
This monitoring function sends a warning before the controller is switched off because of a TRIP (OH)
using the function “Heatsink temperature (fixed)”.
(^ 2-61)
• Thus, the process can be influenced to avoid a switch-off of the controller at an inconvenient
time.
• Additionally, fans which would cause an unacceptable noise in continuous operation, can also
be switched on and off.
MCTRL_bKuehlGreaterC0122_b
is derived from a comparator with hysteresis.
• The threshold can be set under C0122:
Code LCD
Possible settings
IMPORTANT
Lenze Selection
C0122 OH4 limit 85 Temperature threshold prewarning
heatsink temperature “Tht > C0122”
(error OH4)
45 {1 °C} 85
• The hysteresis is 5 K (fixed), i.e. the monitoring is reset at 5 K below the threshold set.
• The response is set under C0852:
Code LCD
Possible settings
IMPORTANT
Lenze Selection
C0582 MONIT OH4 2 Configuration monitoring
2 Warning
3Off
