9300 Servo PLC
System blocks
2.12 MCTRL_MotorControl
2-63
L
ServoPLC EN 2.0
2.12.17.9 OH7 - Motor temperature monitoring (adjustable)
This function monitors the process.
No. Monitoring function Display System variable TRIP Message Warning Off
057 Motor temperature (adjustable) OH7 MCTRL_bMotorTempGreaterC0121_b • ü
• Default setting ü Setting possible
This monitoring function sends a warning before the controller is switched off because of a TRIP
(OH3) using the function “Motor temperature (fixed)”.
(^ 2-61)
• Thus, the process can be influenced to avoid a switch-off of the controller at an inconvenient
time.
• Additionally, fans which would cause an unacceptable noise in continuous operation, can also
be switched on and off.
MCTRL_bMotorTempGreaterC0121_b is derived from a comparator with hysteresis.
• The threshold can be set under C0121:
Code LCD
Possible settings
IMPORTANT
o
Lenze Selection
C0121 OH7 limit 150 Temperature threshold prewarning
motor temperature “TMot > C0121”
(error OH7)
45 {1 °C} 150
• The hysteresis is 15 K (fixed), i.e. the monitoring is reset at 15 K below the threshold set.
• The response is set under C0854:
Code LCD
Possible settings
IMPORTANT
o
Lenze Selection
C0584 MONIT OH7 à Configuration monitoring
à depending on C0086
2 Warning
3Off
• Please also see the corresponding notes in the chapter “Motor temperature monitoring
(fixed)”.
(^ 2-61)
