9300 Servo PLC
System blocks
2.12 MCTRL_MotorControl
2-64
L
ServoPLC EN 2.0
2.12.17.10 OH8 - Motor temperature monitoring via T1, T2
This monitoring function protects the motor.
No. Monitoring function Display System variable TRIP Message Warning Off
058 Motor temperature (PTC) OH8 MCTRL_bPTCOverTemp_b ü ü •
• Default setting ü Setting possible
MCTRL_bPTCOverTemp_b
is derived from the digital signal via the terminals T1, T2 next to the power
terminals UVW.
• The threshold and the hysteresis depend on the encoder system (DIN44081).
• The response is set under C0858:
Code LCD
Possible settings
IMPORTANT
Lenze Selection
C0585 MONIT OH8 3 Configuration monitoring
0TRIP
2 Warning
3Off
Stop!
If you use the input T1, T2 to protect the motor, the monitoring response should not be “Warning”
or “Off”, since the motor could be damaged or destroyed in the event of more overload.
