Lenze i510 Series

Parameter Name / value range / [default seng] Info
0x1601:003 RPDO2 mapping parameter: Applicaon object 3
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 3 for RPDO2.
0x1601:004 RPDO2 mapping parameter: Applicaon object 4
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 4 for RPDO2.
0x1601:005 RPDO2 mapping parameter: Applicaon object 5
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 5 for RPDO2.
0x1601:006 RPDO2 mapping parameter: Applicaon object 6
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 6 for RPDO2.
0x1601:007 RPDO2 mapping parameter: Applicaon object 7
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 7 for RPDO2.
0x1601:008 RPDO2 mapping parameter: Applicaon object 8
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 8 for RPDO2.
0x1602:000 RPDO3 mapping parameter: Number of mapped
applicaon objects in PDO
0 ... [0] ... 8
Number of objects mapped in RPDO3.
0x1602:001 RPDO3 mapping parameter: Applicaon object 1
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 1 for RPDO3.
0x1602:002 RPDO3 mapping parameter: Applicaon object 2
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 2 for RPDO3.
0x1602:003 RPDO3 mapping parameter: Applicaon object 3
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 3 for RPDO3.
0x1602:004 RPDO3 mapping parameter: Applicaon object 4
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 4 for RPDO3.
0x1602:005 RPDO3 mapping parameter: Applicaon object 5
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 5 for RPDO3.
0x1602:006 RPDO3 mapping parameter: Applicaon object 6
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 6 for RPDO3.
0x1602:007 RPDO3 mapping parameter: Applicaon object 7
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 7 for RPDO3.
0x1602:008 RPDO3 mapping parameter: Applicaon object 8
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 8 for RPDO3.
0x1A00:000 TPDO1 mapping parameter: Number of mapped
applicaon objects in TPDO
0 ... [2] ... 8
Number of objects mapped in TPDO1.
0x1A00:001 TPDO1 mapping parameter: Applicaon object 1
0x00000000 ... [0x60410010] ... 0xFFFFFFFF
Mapping entry 1 for TPDO1.
0x1A00:002 TPDO1 mapping parameter: Applicaon object 2
0x00000000 ... [0x60440010] ... 0xFFFFFFFF
Mapping entry 2 for TPDO1.
0x1A00:003 TPDO1 mapping parameter: Applicaon object 3
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 3 for TPDO1.
0x1A00:004 TPDO1 mapping parameter: Applicaon object 4
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 4 for TPDO1.
0x1A00:005 TPDO1 mapping parameter: Applicaon object 5
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 5 for TPDO1.
0x1A00:006 TPDO1 mapping parameter: Applicaon object 6
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 6 for TPDO1.
0x1A00:007 TPDO1 mapping parameter: Applicaon object 7
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 7 for TPDO1.
0x1A00:008 TPDO1 mapping parameter: Applicaon object 8
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 8 for TPDO1.
0x1A01:000 TPDO2 mapping parameter: Number of mapped
applicaon objects in TPDO
0 ... [0] ... 8
Number of objects mapped in TPDO2.
0x1A01:001 TPDO2 mapping parameter: Applicaon object 1
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 1 for TPDO2.
0x1A01:002 TPDO2 mapping parameter: Applicaon object 2
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 2 for TPDO2.
0x1A01:003 TPDO2 mapping parameter: Applicaon object 3
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 3 for TPDO2.
0x1A01:004 TPDO2 mapping parameter: Applicaon object 4
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 4 for TPDO2.
Conguring the network
CANopen
Data mapping
216
