Lenze i510 Series Commissioning

4.2.2.2 Fusing and terminal data
Fuse data
Inverter
I51AE125D
I51AE137D
I51AE155D
I51AE175D
I51AE211D
I51AE215D
I51AE222D
Cable installaon in compliance with EN 60204-1
Installaon method B2
operaon without mains choke
Fuse
Characteriscs gG/gL or gRL
Max. rated current A 10 16 25
Circuit breaker
Characteriscs B
Max. rated current A 10 16 25
operaon with mains choke
Fuse
Characteriscs gG/gL or gRL
Max. rated current A 10 16 25
Circuit breaker
Characteriscs B
Max. rated current A 10 16 25
Earth-leakage circuit breaker
1-phase mains connecon ≥ 30 mA, type A or B
3-phase mains connecon ≥ 30 mA, type B
Fuse data
Inverter I51AE125D
I51AE137D
I51AE155D
I51AE175D
I51AE211D
I51AE215D
I51AE222D
Cable installaon in compliance with US Naonal Electrical Code NFPA 70 / Canadian Electrical Code C22.1
operaon without mains choke
Fuse
Characteriscs all acc. to UL 248 / Class CC
Max. rated current A 15 30
Circuit breaker
Characteriscs -
Max. rated current A 15 30
operaon with mains choke
Fuse
Characteriscs all acc. to UL 248 / Class CC
Max. rated current A 15 30
Circuit breaker
Characteriscs -
Max. rated current A 15 30
Earth-leakage circuit breaker
1-phase mains connecon ≥ 30 mA, type A or B
3-phase mains connecon ≥ 30 mA, type B
Electrical installaon
Mains connecon
3-phase mains connecon 230/240 V
24

Lenze i510 Series Specifications

General

Protection Class	IP20
Overload Capacity	150% for 60 seconds
Enclosure Rating	IP20
Dimensions	Varies by model
Weight	Varies by model
Control Type	V/f control, vector control
Communication Interfaces	CANopen, Modbus RTU, EtherCAT, PROFIBUS, PROFINET
Ambient Temperature	-10°C to +50°C
Braking Resistor	Optional
Safety	STO (Safe Torque Off)
Protection Features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Output Voltage	0 to input voltage
Input Voltage	200-240 V, 380-480 V
Voltage Range	200-240 V, 380-480 V
Frequency Range	0 to 599 Hz
