Lenze i510 Series Commissioning

5 Commissioning
5.1 Important notes
WARNING!
Incorrect wiring can cause unexpected states during the commissioning phase.
Possible consequence: death, severe injuries or damage to property
Check the following before switching on the mains voltage:
▶
Is the wiring complete and correct?
▶
Are there no short circuits and earth faults?
▶
Is the motor circuit conguraon (star/delta) adapted to the output voltage of the inverter?
▶
Is the motor connected in-phase (direcon of rotaon)?
▶
Does the "emergency stop" funcon of the enre plant operate correctly?
WARNING!
Incorrect sengs during commissioning may cause unexpected and dangerous motor and sys-
tem movements.
Possible consequence: death, severe injuries or damage to property
▶
Clear hazardous area.
▶
Observe safety instrucons and safety clearances.
Commissioning
Important notes
34

Lenze i510 Series Specifications

General

Protection Class	IP20
Overload Capacity	150% for 60 seconds
Enclosure Rating	IP20
Dimensions	Varies by model
Weight	Varies by model
Control Type	V/f control, vector control
Communication Interfaces	CANopen, Modbus RTU, EtherCAT, PROFIBUS, PROFINET
Ambient Temperature	-10°C to +50°C
Braking Resistor	Optional
Safety	STO (Safe Torque Off)
Protection Features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Output Voltage	0 to input voltage
Input Voltage	200-240 V, 380-480 V
Voltage Range	200-240 V, 380-480 V
Frequency Range	0 to 599 Hz
