Lenze i510 Series

11.9 Parameter change-over
For up to 32 freely selectable parameters, this funcon provides a change-over between four
sets with dierent parameter values.
DANGER!
Changed parameter sengs are eecve immediately.
The possible consequence is an unexpected response of the motor sha while the inverter is
enabled.
▶
If possible, only carry out parameter changes while the inverter is disabled.
▶
Certain device commands or sengs which might cause a crical state of the drive behav-
iour can generally only be carried our when the inverter is inhibited.
Details
The parameter list is compiled in the same way as that of the "Favorites" via congura-
on. »EASY Starter« provides a user-friendly parameterisaon dialog for this purpose.
Change-over to another value set can oponally be eected via corresponding device com-
mands and/or special funcons/triggers:
4Device commands for parameter change-over ^ 252
4Funcons for parameter change-over ^ 393
Parameter Name / value range / [default seng] Info
0x2022:011
(P700.11)
Device commands: Save parameter set 1
(Device commands: Save par. set 1)
•
For further possible sengs, see parameter
0x2022:001 (P700.01). ^ 249
1 = save value set 1 of the "Parameter change-over" funcon.
•
When the device command has been executed successfully, the value
0 is shown.
0 O / ready
0x2022:012
(P700.12)
Device commands: Save parameter set 2
(Device commands: Save par. set 2)
•
For further possible sengs, see parameter
0x2022:001 (P700.01). ^ 249
1 = save value set 2 of the "Parameter change-over" funcon.
•
When the device command has been executed successfully, the value
0 is shown.
0 O / ready
0x2022:013
(P700.13)
Device commands: Save parameter set 3
(Device commands: Save par. set 3)
•
For further possible sengs, see parameter
0x2022:001 (P700.01). ^ 249
1 = save value set 3 of the "Parameter change-over" funcon.
•
When the device command has been executed successfully, the value
0 is shown.
0 O / ready
0x2022:014
(P700.14)
Device commands: Save parameter set 4
(Device commands: Save par. set 4)
•
For further possible sengs, see parameter
0x2022:001 (P700.01). ^ 249
0 O / ready
0x4041:001 ...
0x4041:032
(P750.01 ... 32)
Parameter change-over: Parameter 1 ... Parameter 32
(Param.set setup: Parameter 1 ... Parameter 32)
0x00000000 ... [0x00000000] ... 0xFFFFFF00
Denion of the parameter list for the "Parameter change-over" func-
on.
•
Format: 0xiiiiss00 (iiii = hexadecimal index, ss = hexadecimal subindex)
•
The lowest byte is always 0x00.
0x4042:001 ...
0x4042:032
(P751.01 ... 32)
Parameter value set 1: Value of parameter 1 ... Value
of parameter 32
(Par. value set 1: Set 1 - Value 1 ... Set 1 - Value 32)
-2147483648 ... [0] ... 2147483647
Value set 1 for the parameter list dened in 0x4041:001 ... 0x4041:032
(P750.01 ... 32).
0x4043:001 ...
0x4043:032
(P752.01 ... 32)
Parameter value set 2: Value of parameter 1 ... Value
of parameter 32
(Par. value set 2: Set 2 - Value 1 ... Set 2 - Value 32)
-2147483648 ... [0] ... 2147483647
Value set 2 for the parameter list dened in 0x4041:001 ... 0x4041:032
(P750.01 ... 32).
0x4044:001 ...
0x4044:032
(P753.01 ... 32)
Parameter value set 3: Value of parameter 1 ... Value
of parameter 32
(Par. value set 3: Set 3 - Value 1 ... Set 3 - Value 32)
-2147483648 ... [0] ... 2147483647
Value set 3 for the parameter list dened in 0x4041:001 ... 0x4041:032
(P750.01 ... 32).
Addional funcons
Parameter change-over
292
