Lenze i510 Series

If the UPS operaon is acve,
•
the device overload monitoring (i*t) is adapted accordingly.
•
the DC limit values are reduced.
•
the phase failure detecon is switched o.
•
the warning "Operaon at UPS acve" (error code 12672 | 0x3180) is output.
•
trigger "UPS operaon acve [118]" is set to TRUE. The trigger can be assigned to a digital
output.
•
bit 15 ("UPS operaon acve") in the inverter status word 2 0x2833 is set to "1".
Notes:
•
An addional limitaon of speed, current, etc. can be realised with the "parameter
change-over". 4Parameter change-over ^ 292
Parameter Name / value range / [default seng] Info
0x2631:055
(P400.55)
Funcon list: Acvate UPS operaon
(Funcon list: Acv. UPS oper.)
•
For further possible sengs, see parameter
0x2631:001 (P400.01). ^ 351
Assignment of a trigger to the "Acvate UPS operaon" funcon.
Trigger = TRUE: Acvate UPS operaon.
Trigger = FALSE: no acon / deacvate funcon again.
0 Not connected
0x2833 Inverter status word 2
•
Read only
Bit-coded status word 2 of the inverter.
Bit 1 Manual test mode acve 1 ≡ manual test mode acve.
Bit 2 Manual control acve 1 ≡ manual control acve.
Bit 6 DC braking acve 1 ≡ DC braking acve.
Bit 15 UPS operaon acve 1 ≡ UPS operaon acve.
Addional funcons
UPS operaon
319
