Constant TRUE [1] Enable inverter
Automatic setpoint selection active [107]
Frequency setpoint selection
via analog input 2
Digital input 1 [11] Run
Digital input 4 [14]
Digital input 3 [13]
Digital input 2 [12]
Rotational direction reversed [69]
Manual setpoint selection active [106]
Running [50]
Stop active [53]
Output signals
Status signals
Output frequency
Activate AI2 setpoint
Activate AI1 setpoint
Invert rotation
Input signals
Frequency setpoint selection
via keypad
(standard setpoint source)
FunctionTrigger
Frequency setpoint selection
via analog input 1
The status signals can be assigned to digital outputs. 4Conguraon of digital outputs ^ 415
①
Change-over from keypad setpoint (standard setpoint source) to AI1 setpoint.
②
Change-over from AI1 setpoint to AI2 setpoint.
③
Change-over from AI2 setpoint to AI1 setpoint since the digital input 3 has a higher priority than the digital input 4.
④
Change-over to keypad setpoint (standard setpoint source).
Flexible I/O conguraon
Setpoint change-over
Analog input setpoint source
