Parameter Name / value range / [default seng] Info
51 Ready for operaon TRUE if inverter is ready for operaon (no error acve, no STO acve and
DC-bus voltage ok). Otherwise FALSE.
52 Operaon enabled TRUE if inverter and start are enabled. Otherwise FALSE.
53 Stop acve TRUE if inverter is enabled and motor is not started and output fre-
quency = 0.
54 Quick stop acve TRUE if quick stop is acve. Otherwise FALSE.
55 Safe torque o (STO) acve TRUE if the integrated safety system has triggered the "Safe torque o
(STO)" funcon. Otherwise FALSE.
56 Error acve TRUE if error is acve. Otherwise FALSE.
57 Error (non-reseable) acve TRUE if non-reseable error is acve. Otherwise FALSE.
58 Device warning acve TRUE if warning is acve. Otherwise FALSE.
A warning has no impact on the operang status of the inverter.
A warning is reset automacally if the cause has been eliminated.
59 Device trouble acve TRUE if a fault is acve. Otherwise FALSE.
In the event of a fault, the motor is brought to a standsll with the
quick stop ramp. The inverter is then disabled.
Excepon: In case of a serious fault, the inverter is disabled immedi-
ately. The motor becomes torqueless (coasts).
The error state will be le automacally if the error condion is not
acve anymore.
The restart behaviour aer trouble can be congured. 4Automac
restart ^ 312
60 Heatsink temperature warning acve TRUE if current heatsink temperature > warning threshold for tempera-
ture monitoring. Otherwise FALSE.
Display of the current heatsink temperature in 0x2D84:001 (P117.01).
Seng of the warning threshold in 0x2D84:002.
66 Flying restart circuit acve TRUE if ying restart circuit acve is acve. Otherwise FALSE.
4Flying restart circuit ^ 309
67 DC braking acve TRUE if DC braking is acve. Otherwise FALSE.
4DC braking ^ 268
69 Rotaonal direcon reversed TRUE if output frequency is negave. Otherwise FALSE.
70 Frequency threshold exceeded TRUE if current output frequency > frequency threshold. Otherwise
FALSE.
Display of the current output frequency in 0x2DDD (P100.00).
Seng Frequency thresholdin 0x4005 (P412.00).
4Frequency threshold for "Frequency threshold exceeded" trigger ^ 407
71 Actual speed = 0
TRUE if current output frequency = 0 Hz (± 0.01 Hz), irrespecve of the
operang mode. Otherwise FALSE.
Display of the current output frequency in 0x2DDD (P100.00).
72 Setpoint speed reached TRUE if frequency setpoint reached. Otherwise FALSE.
73 PID feedback = setpoint TRUE if the controlled variable fed back = process controller setpoint (±
in 0x404D:003 (P608.03) set hysteresis). Otherwise FALSE.
4Basic process controller sengs ^ 239
74 PID idle state acve TRUE if the inverter is in "PID idle state". Otherwise FALSE.
4Process controller idle state ^ 245
75 PID MIN alarm acve TRUE if fed back variable (with acvated PID control) < MIN alarm
threshold. Otherwise FALSE.
Seng of MIN alarm threshold in 0x404D:001 (P608.01).
4Basic process controller sengs ^ 239
76 PID MAX alarm acve TRUE if the fed back variable (with acvated PID control) > MAX alarm
threshold. Otherwise FALSE.
Seng of MAX alarm threshold in 0x404D:002 (P608.02).
4Basic process controller sengs ^ 239
77 PID MIN-MAX alarm acve TRUE if no PID alarm is acve with acvated PID control (MIN alarm
threshold < fed back variable < MAX alarm threshold). Otherwise FALSE.
Seng of MIN alarm threshold in 0x404D:001 (P608.01).
Seng of MAX alarm threshold in 0x404D:002 (P608.02).
4Basic process controller sengs ^ 239
78 Current limit reached
TRUE if current motor current maximum current. Otherwise FALSE.
Display of the present motor current in 0x2D88 (P104.00).
Seng for the maximum current in 0x6073 (P324.00).
Flexible I/O conguraon
Conguraon of digital outputs
Relay
416
