Lenze i510 Series

How to read the keypad parameter list:
Column Meaning
Display code Parameter number on the keypad.
Format: Number.Subindex
Short designaon Short keypad designaon limited to 16 characters.
Default seng Default seng of the parameter.
Seng range Possible seng range for the parameter.
Format: minimum value ... maximum value [unit]
Address Address of the parameter in the object directory.
Format: Index:Subindex
Category Funconal assignment of the parameter, for example "motor control" or "CANopen".
Keypad parameter list (short overview of all parameters with display code)
Display code Short designaon Default seng Seng range Address Category
P100.00 Output frequency x.x Hz - (Read only) 0x2DDD general
P101.00 Scaled act value x Units - (Read only) 0x400D general
P102.00 Freq. setpoint x.x Hz - (Read only) 0x2B0E general
P103.00 Current actual x.x % - (Read only) 0x6078 general
P104.00 Motor current x.x A - (Read only) 0x2D88 general
P105.00 DC-bus voltage x V - (Read only) 0x2D87 general
P106.00 Motor voltage x VAC - (Read only) 0x2D89 general
P107.00 Torque actual x.x % - (Read only) 0x6077 general
P108.xx Output power
└ P108.01 Eecve power x.xxx kW - (Read only) 0x2DA2:001 general
└ P108.02 Apparent power x.xxx kVA - (Read only) 0x2DA2:002 general
P109.xx Output energy
└ P109.01 Motor x.xx kWh - (Read only) 0x2DA3:001 general
└ P109.02 Generator x.xx kWh - (Read only) 0x2DA3:002 general
P110.xx AI1 diagnoscs
└ P110.01 AI1 terminal % x.x % - (Read only) 0x2DA4:001 general
└ P110.02 AI1 scaled freq. x.x Hz - (Read only) 0x2DA4:002 general
└ P110.03 AI1 scaled PID x.xx PID unit - (Read only) 0x2DA4:003 general
└ P110.04 AI1 scaled torq. x.x % - (Read only) 0x2DA4:004 general
└ P110.16 AI1 status - - (Read only) 0x2DA4:016 general
P111.xx AI2 diagnoscs
└ P111.01 AI2 terminal % x.x % - (Read only) 0x2DA5:001 general
└ P111.02 AI2 scaled freq. x.x Hz - (Read only) 0x2DA5:002 general
└ P111.03 AI2 scaled PID x.xx PID unit - (Read only) 0x2DA5:003 general
└ P111.04 AI2 scaled torq. x.x % - (Read only) 0x2DA5:004 general
└ P111.16 AI2 status - - (Read only) 0x2DA5:016 general
P112.xx AO1 diagnoscs
└ P112.01 AO1 Voltage x.xx V - (Read only) 0x2DAA:001 general
└ P112.02 AO1 Current x.xx mA - (Read only) 0x2DAA:002 general
P115.00 Actual sw. freq. - - (Read only) 0x293A general
P117.xx Heatsink temp.
└ P117.01 Heatsink temp. x.x °C - (Read only) 0x2D84:001 general
P118.00 Digital inputs - - (Read only) 0x60FD general
P119.00 Keypad status - - (Read only) 0x2DAC general
P120.00 Int. HW states - - (Read only) 0x2DAD general
P121.xx
└ P121.01 PID setpoint x.xx PID unit - (Read only) 0x401F:001 general
└ P121.02 PID process var. x.xx PID unit - (Read only) 0x401F:002 general
└ P121.03 PID status - - (Read only) 0x401F:003 general
P123.00 Mot. i2t ulis. x % - (Read only) 0x2D4F general
P125.xx Inverter diag.
└ P125.01 Acve control - - (Read only) 0x282B:001 general
* Default seng depending on the size. Firmware version 05.00.00.00
Commissioning
Keypad parameter list
49
