Lenze i510 Series - Page 63

Display code Short designaon Default seng Seng range Address Category
└ P740.45 Parameter 45 0x26390400 0x00000000 ... 0xFFFFFF00 0x261C:045 general
└ P740.46 Parameter 46 0x29110100 0x00000000 ... 0xFFFFFF00 0x261C:046 general
└ P740.47 Parameter 47 0x29110200 0x00000000 ... 0xFFFFFF00 0x261C:047 general
└ P740.48 Parameter 48 0x29110300 0x00000000 ... 0xFFFFFF00 0x261C:048 general
└ P740.49 Parameter 49 0x29110400 0x00000000 ... 0xFFFFFF00 0x261C:049 general
└ P740.50 Parameter 50 0x00000000 0x00000000 ... 0xFFFFFF00 0x261C:050 general
P750.xx Param.set setup
└ P750.01 ... 32 Parameter 1 ... Parameter
32
0x00000000 0x00000000 ... 0xFFFFFF00 0x4041:001 ...
0x4041:032
general
P751.xx Par. value set 1
└ P751.01 ... 32 Set 1 - Value 1 ... Set 1 -
Value 32
0 -2147483648 ... 2147483647 0x4042:001 ...
0x4042:032
general
P752.xx Par. value set 2
└ P752.01 ... 32 Set 2 - Value 1 ... Set 2 -
Value 32
0 -2147483648 ... 2147483647 0x4043:001 ...
0x4043:032
general
P753.xx Par. value set 3
└ P753.01 ... 32 Set 3 - Value 1 ... Set 3 -
Value 32
0 -2147483648 ... 2147483647 0x4044:001 ...
0x4044:032
general
P754.xx Par. value set 4
└ P754.01 ... 32 Set 4 - Value 1 ... Set 4 -
Value 32
0 -2147483648 ... 2147483647 0x4045:001 ...
0x4045:032
general
P755.00 PSet acvaon On op. disabled [0] Selecon list 0x4046 general
P756.xx PSet error msg.
└ P756.01 Status - - (Read only) 0x4047:001 general
└ P756.02 List entry - - (Read only) 0x4047:002 general
P760.xx Fault cong.
└ P760.02 Restart delay 3.0 s 0.0 ... 1000.0 s 0x2839:002 general
└ P760.03 Restart counter 5 0 ... 255 0x2839:003 general
└ P760.04 Tro.count r.me 40.0 s 0.1 ... 3600.0 s 0x2839:004 general
└ P760.05 Trouble counter - - (Read only) 0x2839:005 general
P780.00 CiA: Statusword - - (Read only) 0x6041 general
P781.00 Target velocity 0 rpm -32768 ... 32767 rpm 0x6042 general
P782.00 Velocity demand x rpm - (Read only) 0x6043 general
P783.00 Velocity actual x rpm - (Read only) 0x6044 general
P784.xx Vel. min max
└ P784.01 Vel. min amount 0 rpm 0 ... 480000 rpm 0x6046:001 general
└ P784.02 Vel. max amount 2147483647 rpm 0 ... 2147483647 rpm 0x6046:002 general
P785.xx Vel.acceleraon
└ P785.01 Delta speed 3000 rpm 0 ... 2147483647 rpm 0x6048:001 general
└ P785.02 Delta me 10 s 0 ... 65535 s 0x6048:002 general
P786.xx Vel.deceleraon
└ P786.01 Delta speed 3000 rpm 0 ... 2147483647 rpm 0x6049:001 general
└ P786.02 Delta me 10 s 0 ... 65535 s 0x6049:002 general
P788.00 Modes of op. dis - - (Read only) 0x6061 general
P789.00 Supported modes - - (Read only) 0x6502 general
P790.00 Quick stop dec. 546000 pos. unit/s² 0 ... 2147483647 pos. unit/s² 0x6085 general
P791.00 Fault reacon Coasng [0] Selecon list 0x605E general
P800.00 Sequencer mode Disabled [0] Selecon list 0x4025 general
P801.xx Segment 1
└ P801.01 Frequency setp. 0.0 Hz -599.0 ... 599.0 Hz 0x4026:001 general
└ P801.02 Accel./decel. 5.0 s 0.0 ... 3600.0 s 0x4026:002 general
└ P801.03 Time 0.0 s 0.0 ... 100000.0 s 0x4026:003 general
└ P801.04 Digital outp. 0 0 ... 255 0x4026:004 general
└ P801.05 Analog outp. 0.00 VDC 0.00 ... 10.00 VDC 0x4026:005 general
└ P801.06 PID setp. 0.00 PID unit -300.00 ... 300.00 PID unit 0x4026:006 general
* Default seng depending on the size. Firmware version 05.00.00.00
Commissioning
Keypad parameter list
63
