Mechanical installation
Standard devices in a power range of 0.25 ... 3 kW
Mounting i n ”cold plate” technique
5

110
EDS84ASC552 EN 10.0
”Slim”
TopLine
8400GG105f
Fig. 5-17 Device dimensions
h b t h
1
h
2
t
1
t
2
g
1
g
2
[kW] [mm]
E84AVTCC2512xXS 0.25
215 70 178 236 276 165 205 6 5
E84AVTCC371xxXS 0.37
E84AVTCC551xxXS 0.55
E84AVTCC751xxXS 0.75
E84AVTCC112xxXS 1.1
270 70 178 295 335 165 205 6 5
E84AVTCC152xxXS 1.5
E84AVTCC222xxXS 2.2
E84AVTCC3024xXS 3.0
E84AVTCC2512xBS 0.25
215 70 198 236 276 185 225 6 5
E84AVTCC371xxBS 0.37
E84AVTCC551xxBS 0.55
E84AVTCC751xxBS 0.75
E84AVTCC112xxBS 1.1
270 70 198 295 335 185 225 6 5
E84AVTCC152xxBS 1.5
E84AVTCC222xxBS 2.2
E84AVTCC3024xBS 3.0
