Technical data
HighLine C control terminals
External supply voltage 24 V
4

80
EDS84ASC552 EN 10.0
4.7 HighLine C control terminals
4.7.1 External supply voltage 24 V
Labelling Feature Rated value
X5/24E
Connection for external 24 V supply
voltage by a safely separated
power supply unit (required for
mains-independent supply of the
control electronics and the
communication module)
24 V in accordance with IEC 61131 -2
19.2 ... 28.8 V
Residual ripple max.  5%
SELV/PELV
Suppression of voltage pulses Suppressor diode 36 V, bidirectional
Polarity reversal protection When polarity is reversed: no function and no
destruction
Current consumption
Approx. 0.6 A during operation
Max. 1.5 A starting current for 100 ms
Capacity to be charged 1000 F
X5/GI GND, reference potential for digital signals
Labelling Feature Rated value
X4/24O
Connection for external 24 V supply
voltage by a safely separated
Power supply unit (required for the
supply of the digital outputs)
24 V in accordance with IEC 61131 -2
19.2 ... 28.8 V
Residual ripple max.  5%
SELV/PELV
Suppression of voltage pulses Suppressor diode 36 V, bidirectional
Polarity reversal protection When polarity is reversed: no function and no
destruction
Current consumption Approx. 0.15 A if all digital outputsare loaded with rated
current
X4/GO GND, reference potential for digital signals
Labelling Feature Rated value
X5/24I
24 V voltage ou tput
for connection of the digital inputs via
potential-free contacts
External supply at 24E: voltage drop < 2.5 V
Internal supply: DC 18 ... 28 V
Max. output current 50 mA
Electric strength of external voltage +30 V
Excess current release Automatically resettable
X5/GI GND, reference potential for digital signals
