Electrical installation
TopLine C control terminals
Axis bus
6
241
EDS84ASC552 EN 10.0
6.9.3 Axis bus
Note!
This connection is not supported in versions below 8400 TopLine, SW version
02.00. This connection must not be wired in these lower versions.
X10
,
"
"
"
CAN-Ground
X10
CAN-Low
CAN-High
Sync/State
EDS84AVxxxx
AL
AH
AG
R
R
CA
O
N
AB
AS
AL
AH
AG
AS
120Ω
8400TLC002o 8400TLC009
Terminal data
Conductor cross-section Tightening torque
[mm
2
] [AWG] [Nm] [lb-in]
Flexible
0.2 ... 1.5
24 ... 16 - - -
With wire end ferrule
I/O axis bus
Labelling Feature Rated value
X10/AS I/O axis bus connection TTL level: 5 V
X10/AG GND, reference potential: I/O axis bus
