Lenze L-force E84A Series - Sinusoidal Filters

Accessories (overview)
Sinusoidal filters
11

293
EDS84ASC552 EN 10.0
11.4 Sinusoidal filters
For operation with rated power
Controller Sinusoidal filter
Voltage range Switching
frequency
Inductance Mass
U[V] f
ch
[kHz] L[mH] m[kg]
E84AVxxx3714
EZS3-004A200
0 ... 550 V AC 4...8 11.0 4.0
E84AVxxx5514
E84AVxxx7514
E84AVxxx1124
E84AVxxx1524
EZS3-010A200 0 ... 550 V AC 4...8 5.1 5.5
E84AVxxx2224
E84AVxxx3024xxS
E84AVxxx3024xx0
E84AVxxx4024
EZS3-017A200 0 ... 550 V AC 4...8 3.1 8.5
E84AVxxx5524
E84AVxxx7524 EZS3-024A200
0 ... 550 V AC 4...8
2.5 14.5
E84AVxxx1134 EZS3-032A200 2.0 19.0
E84AVxxx1534 EZS3-037A200 1.7 21.0
E84AVxxx1834 EZS3-048A200
0 ... 550 V AC 4...8
1.2 25.5
E84AVxxx2234 EZS3-061A200 1.0 33.5
E84AVxxx3034 EZS3-072A200 0 ... 550 V AC 4...8 0.95 37.0
E84AVxxx3734 EZS3-090A200
0 ... 550 V AC 4...8
0.8 53.5
E84AVxxx4534 EZS3-115A200 0.7 66.0
For operation with increased power
Controller Sinusoidal filter
Voltage range Switching
frequency
Inductance Mass
U[V] f
ch
[kHz] L[mH] m[kg]
E84AVxxx3714
EZS3-010A200
0 ... 550 V AC 4 5.1 5.5
E84AVxxx5514
E84AVxxx7514
E84AVxxx1124
E84AVxxx1524
E84AVxxx2224
E84AVxxx3024xxS
E84AVxxx3024xx0
EZS3-017A200 0 ... 550 V AC 4 3.1 8.5
E84AVxxx4024
E84AVxxx5524 EZS3-024A200 0 ... 550 V AC 4 2.5 14.5
E84AVxxx7524 EZS3-024A200 0 ... 550 V AC 4 2.5 14.5
E84AVxxx1134 EZS3-037A200 0 ... 550 V AC 4 1.7 21.0
E84AVxxx1534 - - - - -
E84AVxxx1834
EZS3-061A200 0 ... 550 V AC 4 1.0 33.5
E84AVxxx2234
E84AVxxx3034 EZS3-072A200 0 ... 550 V AC 4 0.95 37.0
E84AVxxx3734 EZS3-090A200
0 ... 550 V AC 4
0.8 53.5
E84AVxxx4534 EZS3-115A200 0.7 66.0
