Lenze L-force E84A Series - Operation at a Rated Mains Voltage of 500 V

Technical data
Rated data
Operation at a rated mains voltage of 500 V
4

47
EDS84ASC552 EN 10.0
4.2.4 Operation at a rated mains voltage of 500 V
Basis of the data
Mains Voltage Voltage range Frequency range
U
Lrated
[V] U
Lrated
[V] f[Hz]
3/PE AC 500 400-0%...550+0% 45-0%...65+0%
Mains current at I
aN
Apparent output power Motor power
with external
mains choke
without external
mains choke
U, V, W 4pol.ASM
Type I
LR
[A] I
LR
[A] S
aR
[kVA] P
aR
[kW]
E84AVxxx3714 1.1 1.4 0.8 0.37
E84AVxxx5514 1.4 2.0 1.1 0.55
E84AVxxx7514 2.0 2.6 1.5 0.75
E84AVxxx1124 2.6 3.6 2.0 1.1
E84AVxxx1524 3.1 4.4 2.4 1.5
E84AVxxx2224 4.1 5.8 3.5 2.2
E84AVxxx3024xxS 5.6 7.8 4.5 3.0
E84AVxxx3024xx0 5.6 7.8 4.5 3.0
E84AVxxx4024 7.0 10.5 5.9 4.0
E84AVxxx5524 9.6 14.4 8.1 5.5
E84AVxxx7524 12.0 16.0 10.3 7.5
E84AVxxx1134 16.8 23.2 14.7 11.0
E84AVxxx1534
1)
23.2 - 20.0 15.0
E84AVxxx1834 31.0 43.4 26.1 18.5
E84AVxxx2234
1)
36.1 - 31.5 22.0
E84AVxxx3034
1)
46.9 - 40.5 30.0
E84AVxxx3734
1)
58.2 - 50.7 37.0
E84AVxxx4534
1)
69.2 - 60.0 45.0
1)
only with external mains choke
